Battery Cable Cutting Striping Machine

Battery Cable Cutting Striping Machine

Battery Cable Cutting Striping Machine

Product Description

Model :TM 270

Features

  • Suitable for Cutting, Head-stripping, Middle-stripping and Tail-stripping of single-strand and multi-strand wire
  • Can process wires in such industries as electronic products, electric appliance, toys and auto motorcycle parts, etc.
  • With a microcomputer-controlled very clean designed mechanism, it cuts and strips wire automatically.
  • Various cutting style and programmable length and distance can suit any wire assembly needed.

Specification

Model

TM 270

Power

AC110V/220V 50/60HZ

420*390*280mm

Mode of Display

LCD Liquid Crystal Display Screen

Weight

32KG

Wattage

450W

Cutting Length

1-10000mm

Cutting Tolerance

(0.2±0.002*L)mm

Stripping Length

HEAD 0-50mm,TAIL 0-50mm

Middle Stripping

---

Applicable Size

2-8mm2(AWG5#AWG30#)

Maximum Diameter of Conduit Pipe

8

Material of Knife

Tungsten Steel

Stripping Speed

L=100mm, 2000-5000mm/h

Mode of Driving

Four Wheeled Drive
