Commutator Welding Machine

Commutator Welding Machine Commutator Winding Machine

Commutator Welding Machine

Description

Model: TM-312

Features

-
  • . The machine uses PLC control, touch screen input. More stable performance, easy debugging simple function.
  • The machine uses the motor indexing so that the welding speed faster and more accurate.
  • . The machine uses a special sensor positioning, no need to automatically position the bit. Discharge system automatic voltage regulator.
  • The machine for mold operation is simple and quick, welding needle with water cooling and air cooling in two ways, so that the welding effect is better.

Specifications and indicators:

Indexing Mode Stepping or Servo Motor Automatic Indexing
Adaptation Suitable for Hook, Slot Rectifier Electric Drive Welding.
Rotor Diameter: 15mm-60mm
Commutate Diameter 10mm-50mm
Rotor Shaft Diameter 2mm-15mm
Power Supply AC220V / 20KA.
Equipment Specifications 880mmX700mmX1450mm
Equipment Weight 350kg
