Handheld Fiber Laser Welding Machine

Handheld fiber laser Welding machine


Handheld Fiber Laser Welding Machine


Applicable Materials:

Suitable for welding of gold, silver, titanium, nickel, tin, copper, aluminum and other metal and its alloy material, can achieve the same precision welding between metal and dissimilar metals. Has been widely used in aerospace equipment, shipbuilding, instrumentation, mechanical and electrical products, automotive and other industries.

  1. Stainless Steel Cabinets
  2. Hardware and Bathroom Products
  3. Aluminum Alloy Doorsand Windows
  4. Distribution Box, Chassis
  5. Metal Advertising Stand
  6. Stainless Steel AirDuct Chimney Pipe Spiral Air Duct
  7. Steel Silo.

TECHNICAL PARAMETERS

Laser Source Raycus
Laser Welding Head Hanwei
Nozzles Changeable nozzle tips for multiple purposes
Motor Stepping Motor
Servo Motor Panasonic
Power Supply MEAN WELL
Software Hanwei
Water chiller JZ
Applicable Plate Thickness >3mm
Gap Requirements >0.5mm
Fiber Length 10m
Voltage 220V±5%/50Hz
Total Machine Power 9KW
Cooling Mode Water Colling
Use environment No vibration source, ventilation,18~38°C
Size 900mm L, 600mm W,1050mm H
