Vertical Injection Insert Molding Machine TM-35 Ton

vertical-injection-molding-machine-tm-35-ton

Vertical Injection Insert Molding Machine TM-35 Ton

Product Description

Model: TM 35 Ton

Features

Injection Unit

ModelTM-35 Ton

Screw Diametermm30-32
Injection Pressurekgf/cm21785-1367
Injection Capacitycm374-96
Injection Weightgr100-110
oz3. 0-3. 9
Injection Ratecc/s50-58
Screw SpeedR. P. M0-150
Screw Strokemm120
Nozzle Strokemm150
Nozzle Contact Forcetf2.4

Clamping Unit

Clamping System--Hydraulic
Clamping Forceft35
Clamping Strikemm215
Max Mold Spacemm360
Min Mold Heightmm145
Overall Size Of Platens(HXV)mm600x320
Space Between Columns(HXV)mm450x190
Hydraulic Ejector Forceft0.7
Ejector Strokemm28
